NUX Zeus-jr all isolated power supply

Isolated outputs keep your signal clean

The Zeus Jr. features seven DC outputs that are completely isolated from one another. This prevents signal interference and helps eliminate buzz and hum across your signal chain. Ideal for pedalboards with a mix of high-gain or modulation effects, it ensures stable, interference-free operation.

Multiple voltages for flexible pedal setups

Five outputs deliver 9V at 300mA, while two provide 12V at 500mA. This range supports everything from standard drive pedals to more power-hungry reverbs and delays. You can mix analogue and digital pedals in one setup without needing extra supplies or daisy chains.

Individual protection for every output

Each output includes built-in short-circuit protection. If something goes wrong on one line, the rest of your pedals stay powered and unaffected. This protects your gear and simplifies the process of identifying issues when troubleshooting.

Space-saving design for easy integration

The Zeus Jr. has a slim, lightweight build that fits easily under most pedalboards. This makes it a practical choice for musicians with compact rigs who need reliable power in a discreet format. It’s easy to set up, simple to transport, and dependable during rehearsals or live shows.

Features

• Seven fully isolated outputs reduce noise and prevent signal interference
• Five 9V 300mA outputs power standard pedals with ease
• Two 12V 500mA outputs support higher-draw effects like delays and reverbs
• Each output has short-circuit protection to keep your gear safe
• Low ripple and noise design helps maintain a clean signal
• Compact size fits under most pedalboards to save space
• Durable aluminium chassis is built for regular use and travel
• Includes power cables and mains adapter so you can plug in straight away

Specifications

• Product Code: 173.088UK
• Type: Guitar Pedal Power Supply
• Input Voltage: DC 18V 1.5A (Adapter Included)
• Output: 7 Isolated Outputs
• Output 1–5: 9V DC / 300mA
• Output 6–7: 12V DC / 500mA
• Noise Filter: Low Ripple Noise Design
• Protections: Short Circuit Protection Per Output
• Dimensions (WxDxH): 112mm x 45mm x 25mm
• Weight: 0.16kg
